This meter is a dream come true and sure to be the instant favorite for installers and maintenance technicians.
Some of the significant features include:
Color LCD screen
Up to 16,000 Satellites and Transponders can be entered
DiSEqC switching now allows for switching up to 4 LNBFs
LNBF voltages are now 13v, 18v, and 20v
Drag and drop software upgrading. No need for a software interface. Just plug the meter into the PC's USB port and it will be recognized as a USB compact storage device.
Signal is measured by Signal level, S/N, MER, BER, Time Machine, Spectrum Analysis. Signal can be measured in dBmV, dBµV, dBm.
SF250A Android Smart Phone Meter
Currently available for Android devices only. Not for use on DSS satellites.
This unique meter works with your Android smart phone. Just put the SF250A in your LNBF to Receiver line and you will be able to read signal strength and more on your Android smart phone.
Huge list of satellites and channels. Easily to edit channels or add new channels.
FEATURES
Low noise figure
Signal Strength and Signal Level LED Indicator
Signal lock LED indicator
Built-in Bluetooth BLE for connect to Android devices (phone, tablet, etc)
13V/18V LED indicator
Beeper for remind signal lock function support
1 satellite / 4TP and one LNB type parameters preset
Satellite Finder SH-900HD
SH-900HD DVB-S/S2, Demodulation QPSK, 8PSK, 16APSK, 32APSK, Compatible with DVB-S, DVB-S2, CBS MPEG-4 and ABS-S Signal, Real time Spectrum analyzer, HD CCTV Camera input, DC 12V/2A output, Support Analog, AHD 1.0, 2.0, HD- TVI1.0, 2.0, Support 720P, 960H, 1080P@25/30fps, 7 Inch HD TFT LCD screen, and more
Compatible with DVB-S, DVB-S2, CBS MPEG-4 and ABS-S Signal
Real time Spectrum analyzer
HD CCTV Camera input
DC 12V/2A output
Support Analog, AHD 1.0, 2.0, HD- TVI1.0, 2.0
Support 720P, 960H, 1080P@25/30fps
7 Inch HD TFT LCD screen
MPEG-2/MPEG-4/H.264 decoding Video format and 1080 Full HD
Multi-purpose design
Easy operation OSD design
Quick satellite signal finding
Program play, video monitoring
Quick satellite antenna installation
Global satellite data preset
Satellite parameters editable
Support DISEqC1.0, DISEqC1.1
Easy operation DISEqC1.2, USALS OSD design
Multiple satellites/TPs scan, blind scan and NIT scan
Display POWER, BER, MER, C/N, NIT value
Sound prompt when signal locked
Signal locked indicating light
13/18 volts indicating lights
22KHz indicating light
LCD backlight turns off automatically
LNB short-circuit protection and warning
Audio and video input/output
HDMI output
Upgrade software & parameters through RS232, USB2.0
Support USB PVR, MP3, JPG photo playback
Removable battery design
High capacity LI-ION battery (11.1V 3200mA), can last around 3 hours
Length x width x height: 22.5 x 16x 4.5 cm
Weight: 0.8Kg
Gross weight: 1.3Kg
Carton size: 61*29 *23cm (5 pieces for one carton)
Weight: 14Kg
Satellite Finder SH-910HD
SH-910HD DVB-S/S2, Demodulation QPSK, 8PSK, 16APSK, 32APSK, Compatible with DVB-S, DVB-S2, CBS MPEG-4 and ABS-S Signal, Real time Spectrum analyzer,Support auto DiSEqc1.0,1.1, 7 Inch HD TFT LCD screen, High capacity LI-ION battery
Compatible with DVB-S, DVB-S2, CBS MPEG-4 and ABS-S Signal
Real time Spectrum analyzer
DC 12V/2A output
7 Inch HD TFT LCD screen
MPEG-2/MPEG-4/H.264 decoding Video format and 1080 Full HD
Multi-purpose design
Easy operation OSD design
Quick satellite signal finding
Program play,video monitoring
Quick satellite antenna installation
Global satellite data preset
Satellite parameters editable
Support DISEqC1.0, DISEqC1.1
Easy operation DISEqC1.2, USALS OSD design
Support auto DiSEqc1.0, 1.1
Multiple satellites/TPs scan, blind scan and NIT scan
Display POWER, BER, MER, C/N, NIT value
Sound prompt when signal locked
Signal locked indicating light
13/18 volts indicating lights
22KHz indicating light
LCD backlight turns off automatically
LNB short-circuit protection and warning
Audio and video input/output
HDMI output
Upgrade software & parameters through U Disk
Support USB PVR, MP3, JPG photo playback
Removable battery design
High capacity LI-ION battery (11.1V 3800mA), can last around 3 hours
Length x width x height: 22.5 x 16x 4.5 cm
Weight: 0.8Kg
Gross weight: 1.3Kg
Gift box: 33.5 x 22.5 x 7.5 cm
Carton size:68.5 x 37.5 x 25cm (10 pieces for one carton)
Weight: 14Kg
Satellite Finder SH-800HD
SH-800HD SATHERO SH-800HD DVB-S2 SAT Finder, Digital satellite finder, Digital satellite meter,DVB-S/S2,Spectrum analyzer, MPEG-2/MPEG-4/H.264 decoding Video format and 1080 Full HD, Upgrade software & parameters through RS232, USB2.0
Compatible with DVB-S, DVB-S2, CBS MPEG-4 and ABS-S Signal
Spectrum analyzer
3.5 Inch HD TFT LCD screen
MPEG-2/MPEG-4/H.264 decoding Video format and 1080 Full HD
Multi-purpose design
Easy operation OSD design
Quick satellite signal finding
Program play, video monitoring
Quick satellite antenna installation
Global satellite data preset
Satellite parameters editable
Support DISEqC1.0, DISEqC1.1
Easy operation DISEqC1.2, USALS OSD design
Multiple satellites/TPs scan, blind scan and NIT scan
Display POWER, BER, MER, C/N, NIT value
Sound prompt when signal locked
Signal locked indicating light
13/18 volts indicating lights
22KHz indicating light
LCD backlight turns off automatically
LNB short-circuit protection and warning
Audio and video input/output
HDMI output
Upgrade software & parameters through RS232, USB2.0
Support USB PVR, MP3, JPG photo playback
Removable battery design
High capacity LI-ION battery (2550mA), can last around 3 hours
Length x width x height: 17.5 x 12.5 x 3.5 cm
Weight: 0.55Kg
Gross weight: 1.0Kg
Carton size: 53.5*37*21.5cm (10 pieces for one carton)
Weight: 12Kg
Satellite Finder SH-500HD
SH-500HD Support DVB-S/S2 Support QPSK, 8PSK, 16APSK, 32APSK Support DISEqC1.0, DISEqC1.1, DISEqC1.2, USALS Display POWER, BER, MER, C/N, NIT value Audio and video input/output, HDMI1.4 output High capacity LI-ION battery (11.1V 2550mA), can last around 4 hours
Compatible with DVB-S, DVB-S2, CBS MPEG-4 and ABS-S Signal
Automatically identify DVB S/S2/T/T2 signals
Satellite name and longitude are listed simultaneously
22KHz switch automatically
Global satellite data preset
Satellite parameters editable
Display POWER, a.BER、MER and, C/N value
High-resolution backlit LCD easy read
LCD backlight turns off automatically
Signal quality indication LEDs
Signal lock prompt audio tone
13/18 volts indicating lights
22KHz indicating light
Signal lock indicating light
Antenna Power Supply 5V, max 100 mA
LNB short-circuit protection
Upgrade software & parameters through USB2.0 Port
Wrist strap included
Global AC power charger included
Removable battery design
High capacity LI-ION battery (1850mA), can last around 4 hours
Length x width x height 12.7 x 8 x 3.2 cm
Weight 0.28Kg
Gross weight 0.65Kg
Carton size：56.5*37.5*24cm (10 pieces for one carton)
Weight 12Kg(10 pieces)
Satellite Finder SH-200HD
SH-200HD SH-200HD DVB S2 SAT Finder Support QPSK, 8PSK, 16APSK, 32APSK Compatible with DVB-S, DVB-S2, CBS MPEG-4 and ABS-S Signal Automatically identify DVB S and S2 signals Display POWER, a.BER, MER and C/N value Upgrade software & parameters through USB2.0 Port High capacity LI-ION battery (1850mA), can last around 4 hours
